CI/LCI

• Identifies a de-energized primary cable safely
• Identifies live secondary cables up to 240 V AC
• Avoids false positives
• Easy and safe to operate

The CI/LCI cable identifier will safely identify a dead (or de-energized) primary cable within a group of energized or de-energized cables. It can also identify live secondary cables, including neutrals, up to 240 V AC (440 optional).

This absolutely safe identification method done by the CI/LCI is based on polarity and signal magnitude of the DC pulse (up to 100 A) coming from the transmitter, which is picked up by the receiver and a clip-on probe. The transmitter can operate on 120 V AC or via its internal battery that gives you up to 50 hours run time. The entire CI/LCI system functions without user adjustments and will never provide a false positive identification.

The standard combination kit, for high and low voltage cables, includes a 6-inch flexible clip-on probe and two touch sensors for all the applications where a clip-on cannot be used.
